Good, smooth running of tools and other rotating bodies is indispensable.

Use the balancing machines TS20, TS40, TS100 for tool and workpiece testing.

For all tools, e.g. SK and BT from size 10 – 50 and HSK from size 25 – 100, as well as CAPTO and KM holders. Ideal for 1- and 2-plane balancing.

  • You save time and money.
  • You gain security.
  • Your machine spindles live longer.
  • Your production result will be better.

PRODUCT

Balancing station BMT200.TS20

Especially for small tool holders up to HSK32 / SK30 in the high-speed range

  • Highest balancing accuracy at the best price
  • Especially for small tool holders up to HSK32 / SK30
  • Simplest operation for everyone
  • Smallest (<0.1 gram) unbalances detectable
  • Highest precision (< 0,5gmm)
  • Improved ease of use > 90%
  • For 1-+ 2-plane balancing
  • Balancing methods: gram, degree, spread angle, fixed location, radial + axial drilling, milling
  • Display: gmm, gram, quality grade
  • Workpiece weight up to approx.: 750g
  • Workpiece-Ø up to approx. 270mm
  • Workpiece length up to approx. 280mm
  • Immediately usable
  • Test report at the touch of a button
  • Weight only approx. 38kg
Balancing station BMT200.TS40

For tool holders up to HSK63 / SK40 / PSC 5

  • Highest balancing accuracy at the best price
  • Simplest operation for everyone
  • Smallest (< 0.1 gram) imbalances detectable
  • For tool holders up to HSK63 / SK40 / PSC 5
  • Highest precision
  • Improved ease of use > 90%.
  • For 1-+ 2-plane balancing
  • Balancing methods: gram, degree, spread angle, fixed location, radial + axial drilling, milling
  • Display: gmm, gram, quality grade
  • Workpiece weight up to max.: 10kg, workpiece-Ø up to approx. 270mm
  • Workpiece length up to approx. 400mm
  • Immediately usable
Balancing station BMT200.TS100

For tool holders up to HSK100 / SK50 / PSC 8
3.BMT200-1.TS100 (1 plane 1039707A)
3.BMT200-2.TS100 (1 + 2-planes 1039708A)

  • Highest balancing accuracy at the best price
  • Simplest operation for everyone
  • Smallest (< 0.1 gram) imbalances detectable
  • For tool holders up to HSK100 / SK50 / PSC 8
  • Highest precision
  • Improved ease of use > 90%.
  • For 1-+ 2-plane balancing
  • Balancing methods: gram, degree, spread angle, fixed location, radial + axial drilling, milling
  • Display: gmm, gram, quality grade
  • Workpiece weight up to max.: 20kg, workpiece-Ø up to approx. 270mm
  • Workpiece length up to approx. 400mm
  • Immediately usable
  • Test report at the touch of a button
  • Weight only approx. 45 kg
